DC 6-30V Relay Module Trip Delay with delayed power-off and disconnect and trigger delay -BLACK Relay [Micro USB]

SKU: FA219-0
Input Voltage

DC 6V – 30V (Micro USB 5V option)
Relay Rating

10A at 250V AC / 30V DC
Channels

1 (single-channel)
Timing Functions

Delayed power-off, disconnect timing, trigger delay
Display

Digital LED display
Configuration

Onboard buttons
Terminal Type

Screw terminals
Relay Color

Black

The DC 6-30V Relay Module Trip Delay is a versatile, programmable timing relay board designed for automated control of electrical devices with delayed power-off, disconnect timing, and trigger delay functions. It combines a high-current relay with an adjustable timer circuit, making it an ideal solution for applications requiring precise time-based switching — from industrial automation to home automation and DIY electronics.

The module operates from a wide DC 6V to 30V input range, making it compatible with 12V and 24V systems, as well as battery-powered setups. It also supports Micro USB 5V power input, providing a convenient alternative power source for bench testing and configuration. The onboard high-current relay is rated for 10A at 250V AC or 30V DC, capable of directly switching lamps, motors, pumps, solenoids, and other loads.

The module offers multiple timing functions to suit different control requirements. Delayed power-off allows the relay to remain active for a set period after the trigger signal is removed. Disconnect timing enables the relay to deactivate after a specified duration. Trigger delay allows a delay before the relay activates following a trigger signal. These functions are configurable through the onboard buttons and displayed on the digital LED display.

The module features a digital LED display that shows the current time settings and operating status, making configuration straightforward. The onboard buttons allow you to adjust delay times, operating modes, and other parameters without any external programmer or computer. The screw terminals provide secure connections for power, trigger input, and relay output. The black relay designation indicates the relay housing color.

The module is widely used in industrial control, home automation, lighting control, motor sequencing, security systems, and DIY timing projects. Its compact form factor and simple operation make it suitable for both beginners and experienced users.

Whether you are automating a delayed lighting system, sequencing motors in an industrial process, or building a custom timing circuit, the DC 6-30V Relay Module Trip Delay provides a reliable, programmable solution. It is suitable for individual makers, students, and businesses purchasing in bulk for product development or educational programs.

Features

  • Wide input voltage — DC 6V to 30V operating range

  • Micro USB 5V power option — Convenient alternative power source

  • High-current relay — 10A at 250V AC / 30V DC switching capacity

  • Delayed power-off function — Relay remains active for set period after trigger removal

  • Disconnect timing — Relay deactivates after specified duration

  • Trigger delay — Adjustable delay before relay activation

  • Digital LED display — Shows time settings and operating status

  • Onboard buttons — Configure modes and timings without external tools

  • Screw terminals — Secure connections for power, trigger, and load

  • Black relay — Distinctive relay housing color for easy identification

Technical Specifications

# Parameter Specification
1 Input Voltage DC 6V – 30V (Micro USB 5V option)
2 Relay Rating 10A at 250V AC / 30V DC
3 Channels 1 (single-channel)
4 Timing Functions Delayed power-off, disconnect timing, trigger delay
5 Display Digital LED display
6 Configuration Onboard buttons
7 Terminal Type Screw terminals
8 Relay Color Black

Usage

Getting Started

  1. Connect power — Supply DC 6V–30V to the power input terminals, or connect Micro USB 5V for bench testing.

  2. Connect the trigger input — Wire your trigger signal source to the trigger input terminals.

  3. Connect the load — Wire the device you want to control to the relay output terminals (NO/NC/COM).

  4. Configure the timing functions — Use the onboard buttons to select the desired mode and set the timing values. The LED display shows the current settings.

  5. Power on and test — Apply power and trigger signal. The relay will activate according to your configured timing.

Timing Function Descriptions

Function Behavior Application
Delayed Power-Off Relay stays active for set time after trigger removal Delayed lighting, fan run-on
Disconnect Timing Relay deactivates after set duration Timed motor operation, process control
Trigger Delay Relay activates after set delay following trigger Delayed start, sequencing

Typical Applications

  • Industrial control — Motor sequencing, process timing, equipment protection

  • Home automation — Delayed lighting, automatic garden irrigation

  • Lighting control — Timed on/off cycles, delayed shutoff

  • Motor control — Start/stop delays, run-on timers

  • Security systems — Timed alarm activation, door lock delays

  • DIY timing projects — Custom timing circuits for various applications

Notes for Business Buyers

  • Versatile timing functions — One module supports multiple timing modes, reducing inventory SKUs.

  • Wide voltage compatibility — Works with 6V–30V systems and Micro USB 5V power.

  • High-current relay — 10A capacity covers most small-to-medium power devices.

  • Suitable for bulk purchasing — Ideal for industrial control, automation, and educational programs.

Q: What is the DC 6-30V Relay Module Trip Delay used for?

It is a programmable timing relay for automated control of electrical devices, supporting delayed power-off, disconnect timing, and trigger delay functions.

Q: What is the input voltage range?

The module operates from DC 6V to 30V, and also supports Micro USB 5V power input.

Q: What is the relay rating?

The relay is rated for 10A at 250V AC or 30V DC.

Q: What timing functions does the module support?

It supports delayed power-off, disconnect timing, and trigger delay functions.

Q: How do I configure the timing?

Use the onboard buttons to select the mode and adjust timing values. The digital LED display shows the current settings.

Q: Does the module require an external programmer?

No. All configuration is done through the onboard buttons and LED display — no external programmer or computer is required.

Q: Can I control AC devices with this module?

Yes, if the relay is rated for AC voltage. The relay contacts can switch loads up to 250V AC / 10A. Ensure proper safety precautions when working with mains voltage.

Q: What is the difference between delayed power-off and disconnect timing?

Delayed power-off: the relay remains active for a set time after the trigger signal is removed. Disconnect timing: the relay deactivates after a specified duration.

Q: Does the module have a Micro USB port?

Yes. The module includes a Micro USB port for 5V power input, useful for bench testing and configuration.

Q: Can I purchase in bulk for an industrial project?

Yes. This module is suitable for both individual users and business purchasing, including industrial control, home automation, and educational programs.
